Boundary models
Daniel C. Reuman
Department of Ecology and Evolutionary Biology and Center for Ecological Research, University of KansasEmilio Berti
German Center for Integrative Biodiversity ScienceSource:
vignettes/03-boundary_models.Rmd
03-boundary_models.Rmd\[ \newcommand{\mean}[1]{\overline{#1}} \newcommand{\var}{\text{var}} \newcommand{\cov}{\text{cov}} \newcommand{\cor}{\text{cor}} \newcommand{\Rp}{\text{Re}} \newcommand{\E}{\text{E}} \newcommand{\ltsgr}{\text{ltsgr}} \newcommand{\expit}{\text{expit}} \newcommand{\logit}{\text{logit}} \]
Abstract. We here show an example of the not uncommon case where the seemingly best initial model considered does not show adequate evidence that the likelihood function was fully optimized; the best parameters obtained by optimization show \(p_d\) close to \(1\); and the profile for \(p_d\) is not dome shaped. The boundary model with \(p_d = 1\) can then be used. This example is based on occurrence data from GBIF for Blarina carolinensis, the southern short-tailed shrew.
The southern short-tailed shrew, Blarina carolinensis, is found in the southeastern United States.
We start by loading in the data:
## [1] 1156 39 6
dimnames(env_array)[[3]]## [1] "BIO01" "BIO10" "BIO11" "BIO12" "BIO16" "BIO17"
occ <- example_3$occ_vec
length(occ)## [1] 1156Here, there are 6 environmental variables recorded for 39 years in
1156 locations, with accompanying detections and pseudo-absences in the
variable occ. The first three environmental variables
(BIO1, BIO10, BIO11) are temperature variables, and the last three
(BIO12, BIO16, BIO17) are precipitation variables. BIO1 is mean annual
temperature, BIO10 is mean temperature of the warmest quarter, BIO11 is
mean temperature of the coldest quarter, BIO12 is annual precipitation,
BIO16 is precipitation of the wettest quarter, and BIO17 is
precipitation of the driest quarter.
Now look at the distributions of values of environmental variables to make sure they are not on wildly different scales, which could cause problems for optimization:
## BIO01 BIO10 BIO11 BIO12 BIO16 BIO17
## 2.5% 11.62000 21.71 1.48 76.36075 9.13 2.1300
## 25% 15.32000 25.25 6.29 108.63000 13.19 4.5075
## 50% 17.16000 26.45 9.06 126.30000 15.76 5.9500
## 75% 19.20000 27.44 11.99 146.79000 18.84 7.3800
## 97.5% 22.55925 29.22 17.61 190.28000 27.05 10.4200These distributions look basically OK.
Now fit 15 models, each from 25 starting conditions:
models <- matrix(c(1,0,0,0,0,0,
0,1,0,0,0,0,
0,0,1,0,0,0,
0,0,0,1,0,0,
0,0,0,0,1,0,
0,0,0,0,0,1,
1,0,0,1,0,0,
1,0,0,0,1,0,
1,0,0,0,0,1,
0,1,0,1,0,0,
0,1,0,0,1,0,
0,1,0,0,0,1,
0,0,1,1,0,0,
0,0,1,0,1,0,
0,0,1,0,0,1), nrow=15, byrow=TRUE)
all_model_results <- list()
for (i in 1:nrow(models))
{
env_dat <- env_array[,,models[i,]==1,drop=FALSE]
starts <- start_parms(env_dat[occ==1,,,drop=FALSE],num_starts=25)
all_optim_results <- list()
for (j in 1:nrow(starts))
{
all_optim_results[[j]] <- optim(par=starts[j,],fn=loglik_math,
method="BFGS",
env_dat=env_dat, occ=occ,negative=TRUE,
control=list(trace=0))
}
all_model_results[[i]] <- all_optim_results
}Rank the models by BIC, bearing in mind that we’ve been working with the negative of the likelihood:
model_BICs <- sapply(X=all_model_results,
FUN=function(x){
best_loglik = min(sapply(X=x, FUN=function(y){y$value}))
num_parms = length(x[[1]]$par)
n = length(occ)
BIC = 2*best_loglik + num_parms*log(n)
return(BIC)
}
)Also by AIC, and compare the two:
model_AICs <- sapply(X=all_model_results,
FUN=function(x){
best_loglik = min(sapply(X=x, FUN=function(y){y$value}))
num_parms = length(x[[1]]$par)
AIC = 2*best_loglik + 2*num_parms
return(AIC)
}
)
inds <- order(model_BICs)
rbind(model_BICs[inds],model_AICs[inds])## [,1] [,2] [,3] [,4] [,5] [,6] [,7] [,8]
## [1,] 1165.087 1172.644 1175.913 1190.903 1193.872 1194.662 1196.464 1201.075
## [2,] 1119.613 1127.170 1150.649 1145.429 1148.398 1149.187 1171.201 1155.600
## [,9] [,10] [,11] [,12] [,13] [,14] [,15]
## [1,] 1201.277 1202.069 1210.063 1216.147 1288.862 1292.384 1310.536
## [2,] 1155.803 1156.595 1164.588 1190.883 1263.598 1267.121 1285.273
plot(model_BICs,model_AICs,type="p",xlab="BIC",ylab="AIC")
order(model_BICs)## [1] 9 12 2 7 8 15 1 11 10 13 14 3 5 4 6
order(model_AICs)## [1] 9 12 7 8 15 2 11 10 13 14 1 3 5 4 6Looks like in this case the AIC and the BIC are reasonably aligned with each other. Look at the best two models:
models[order(model_BICs)[1:2],]## [,1] [,2] [,3] [,4] [,5] [,6]
## [1,] 1 0 0 0 0 1
## [2,] 0 1 0 0 0 1So these are two-variable models.
Let’s use the best model. Optimize it a bit harder:
i <- 9
env_dat <- env_array[,,models[i,]==1,drop=FALSE]
starts <- start_parms(env_dat[occ==1,,,drop=FALSE],num_starts=100)
best_model_results <- list()
for (j in 1:nrow(starts))
{
best_model_results[[j]] <- optim(par=starts[j,],fn=loglik_math,
method="BFGS",
env_dat=env_dat, occ=occ,negative=TRUE,
control=list(trace=0))
}
values <- sapply(X=best_model_results, FUN=function(y){y$value})
inds <- order(values)
best_model_results <- best_model_results[inds]
min(sapply(X=all_model_results[[i]], FUN=function(y){y$value}))## [1] 550.8064
best_model_results[[1]]$value## [1] 550.8064Pretty similar, so we HAD pretty much fully optimized before.
Now have a look at the result for this model.
examine_optim_results <- function(optim_results,mask=NULL)
{
#put optimization results in order from best to worst
bestlogliks <- sapply(X=optim_results,FUN=function(x){x$value})
inds <- order(bestlogliks)
bestlogliks <- bestlogliks[inds]
optim_results <- optim_results[inds]
#model convergence
convergences <- sapply(X=optim_results,FUN=function(x){x$convergence})
#compute distances to the best result in parameter space
best_parms_math <- optim_results[[1]]$par
parms_dists_to_best <- lapply(
X=optim_results,
FUN=function(x){
dist_between_params(
x$par,
best_parms_math,
mask=mask,
give_closest_rep=TRUE)
}
)
parms_dists <- sapply(X=parms_dists_to_best, FUN=function(x){x$distance})
#get the parameters from each optimization run which are closest to the first set
bestparms <- sapply(X=parms_dists_to_best, FUN=function(x){unlist(x$representative)})
#put it all together
return(rbind(bestlogliks,convergences,parms_dists,bestparms))
}
h <- examine_optim_results(best_model_results)
t(h[,1:8])## bestlogliks convergences parms_dists mu1 mu2 sigltil1 sigltil2
## [1,] 550.8064 0 0.0000000000 14.26739 3.550976 4.605441 0.4572114
## [2,] 550.8064 0 0.0006586953 14.26706 3.551155 4.605143 0.4571020
## [3,] 550.8064 0 0.0003171643 14.26754 3.550946 4.605450 0.4572566
## [4,] 550.8064 0 0.0006132105 14.26707 3.551124 4.605419 0.4571075
## [5,] 550.8064 0 0.0008011962 14.26777 3.550840 4.605461 0.4573422
## [6,] 550.8064 0 0.0000799259 14.26737 3.550959 4.605582 0.4572064
## [7,] 550.8064 0 0.0003904173 14.26754 3.550937 4.605617 0.4572566
## [8,] 550.8064 0 0.0016968145 14.26737 3.551223 4.604871 0.4572748
## sigrtil1 sigrtil2 ctil pd o_mat1 o_mat2 o_mat3
## [1,] 0.1482753 4.892247 -0.1916786 0.9999978 -0.2430936 -0.9700028 0.9700028
## [2,] 0.1482779 4.892511 -0.1917463 0.9999901 -0.2431073 -0.9699994 0.9699994
## [3,] 0.1482788 4.892006 -0.1917135 0.9999874 -0.2430854 -0.9700049 0.9700049
## [4,] 0.1482767 4.892354 -0.1917055 0.9999872 -0.2431085 -0.9699991 0.9699991
## [5,] 0.1482815 4.892294 -0.1916588 0.9999870 -0.2430725 -0.9700081 0.9700081
## [6,] 0.1482744 4.892272 -0.1916193 0.9999868 -0.2430970 -0.9700020 0.9700020
## [7,] 0.1482813 4.892361 -0.1916116 0.9999795 -0.2430852 -0.9700049 0.9700049
## [8,] 0.1483115 4.893160 -0.1916173 0.9999781 -0.2430938 -0.9700028 0.9700028
## o_mat4
## [1,] -0.2430936
## [2,] -0.2431073
## [3,] -0.2430854
## [4,] -0.2431085
## [5,] -0.2430725
## [6,] -0.2430970
## [7,] -0.2430852
## [8,] -0.2430938This looks good, in the sense that it looks like multiple optimizations arrived at the same place in parameter space, which is some evidence that we may have found the global maximum of the likelihood function. The only problem is that \(p_d\) is very close to \(1\).
Let’s profile this model and see what we get:
pnames <- names(make_mask_names(2))
all_profiles <- list()
linc <- c(rep(0.05,8),0.01)
rinc <- c(rep(0.05,8),0.01)
for (counter in 1:9)
{
all_profiles[[counter]] <- profile_likelihood(
profile_parameter=pnames[counter],
increment_left=linc[counter],
increment_right=rinc[counter],
num_steps_left=50,
num_steps_right=50,
alpha=0.95,
optim_param_vector=best_model_results[[1]]$par,
env_dat=env_dat,
occ=occ,
mask=NULL,
num_threads=6
)
}
names(all_profiles) <- pnamesNow plot these profiles:
plot_tool <- function(ap,index)
{
x <- ap[[index]]$profile$value_math
y <- ap[[index]]$profile$loglik
xlab <- names(ap)[index]
thresh <- ap[[index]]$threshold
plot(x,y,
type="o",xlab=xlab,
ylab="Log likelihood")
lines(range(x),rep(thresh,2),type="l",
lty="dashed",col="red")
}
par(mfrow=c(3,3))
plot_tool(all_profiles,1)
plot_tool(all_profiles,2)
plot_tool(all_profiles,3)
plot_tool(all_profiles,4)
plot_tool(all_profiles,5)
plot_tool(all_profiles,6)
plot_tool(all_profiles,7)
plot_tool(all_profiles,8)
plot_tool(all_profiles,9)
So yes, the expected problem with pd is appearing. We
cannot use a model for which profiles do not show a dome-like pattern.
This is a common problem and it manifests in the manner illustrated
here.
The solution is to use the boundary model with \(p_d = 1\):
env_dat <- env_array[,,models[i,]==1,drop=FALSE]
dim(env_dat)## [1] 1156 39 2
mask <- c(pd=Inf) #use Inf because masks are given on the math scale
mask## pd
## Inf
new_starts <- start_parms(env_dat[occ==1,,,drop=FALSE],
mask=mask,num_starts=100)
head(new_starts)## # A tibble: 6 × 8
## mu1 mu2 sigltil1 sigltil2 sigrtil1 sigrtil2 ctil o_par1
## <dbl> <dbl> <dbl> <dbl> <dbl> <dbl> <dbl> <dbl>
## 1 15.6 7.89 0.299 1.05 1.19 0.702 -1.32 -3.39
## 2 18.1 5.24 0.992 0.355 0.498 1.40 -0.743 6.04
## 3 19.3 6.57 -0.0473 0.702 1.54 0.356 -1.60 -8.10
## 4 16.9 3.92 0.646 0.00881 0.844 1.05 -1.03 1.33
## 5 17.5 5.91 0.126 0.875 1.36 0.183 -1.46 -5.74
## 6 19.9 8.55 0.819 0.182 0.671 0.876 -0.886 3.68
bdry_optim_results <- list()
for (j in 1:nrow(new_starts))
{
bdry_optim_results[[j]] <- optim(par=new_starts[j,],fn=loglik_math,
method="BFGS",
env_dat=env_dat,occ=occ,mask=mask,negative=TRUE,
control=list(trace=0,maxit=500))
}Have a look at these results:
h <- examine_optim_results(bdry_optim_results,mask=mask)
t(h[,1:8])## bestlogliks convergences parms_dists mu1 mu2 sigltil1 sigltil2
## [1,] 550.8063 0 0.000000e+00 14.26741 3.550951 0.1482747 4.892239
## [2,] 550.8063 0 4.374443e-05 14.26740 3.550958 0.1482741 4.892262
## [3,] 550.8063 0 5.187592e-05 14.26744 3.550951 0.1482751 4.892222
## [4,] 550.8063 0 2.199448e-05 14.26741 3.550962 0.1482748 4.892246
## [5,] 550.8063 0 3.983488e-05 14.26740 3.550954 0.1482753 4.892266
## [6,] 550.8063 0 9.529778e-05 14.26745 3.550929 0.1482731 4.892174
## [7,] 550.8063 0 6.799521e-05 14.26739 3.550974 0.1482754 4.892249
## [8,] 550.8063 0 6.067718e-05 14.26740 3.550968 0.1482757 4.892246
## sigrtil1 sigrtil2 ctil pd o_mat1 o_mat2 o_mat3 o_mat4
## [1,] 4.605536 0.4572214 -0.1916681 1 0.2430902 0.9700037 -0.9700037 0.2430902
## [2,] 4.605472 0.4572158 -0.1916731 1 0.2430897 0.9700038 -0.9700038 0.2430897
## [3,] 4.605392 0.4572290 -0.1916862 1 0.2430872 0.9700044 -0.9700044 0.2430872
## [4,] 4.605468 0.4572182 -0.1916753 1 0.2430905 0.9700036 -0.9700036 0.2430905
## [5,] 4.605618 0.4572173 -0.1916540 1 0.2430890 0.9700040 -0.9700040 0.2430890
## [6,] 4.605459 0.4572284 -0.1916864 1 0.2430900 0.9700037 -0.9700037 0.2430900
## [7,] 4.605460 0.4572110 -0.1916809 1 0.2430915 0.9700034 -0.9700034 0.2430915
## [8,] 4.605406 0.4572140 -0.1916786 1 0.2430895 0.9700039 -0.9700039 0.2430895This looks like enough of them converged to the same thing to say that it looks like I successfully optimized. Get the likelihood:
values <- sapply(X=bdry_optim_results, FUN=function(y){y$value})
inds <- order(values)
bdry_optim_results <- bdry_optim_results[inds]
best_model_results[[1]]$value## [1] 550.8064
bdry_optim_results[[1]]$value## [1] 550.8063So the likelihood is the same as for the previous (non-boundary) model. But we have one less parameter that has been fitted. Get the AIC and BIC to see the effects:
AIC <- unname(2*bdry_optim_results[[1]]$value+
2*length(bdry_optim_results[[1]]$par))
AIC_old <- unname(2*best_model_results[[1]]$value+
2*length(best_model_results[[1]]$par))
AIC## [1] 1117.613
AIC_old## [1] 1119.613
AIC-AIC_old## [1] -2.000019
BIC <- unname(2*bdry_optim_results[[1]]$value+
log(length(occ))*length(bdry_optim_results[[1]]$par))
BIC_old <- unname(2*best_model_results[[1]]$value+
log(length(occ))*length(best_model_results[[1]]$par))
BIC## [1] 1158.034
BIC_old## [1] 1165.087
BIC-BIC_old## [1] -7.05274## [1] 7.052721So the AIC and BIC are better for the boundary model compared to the earlier model, and by the expected amounts. We go with the boundary model.
Let’s profile this boundary model and see what we get:
pnames <- names(make_mask_names(2))
pnames <- pnames[pnames!="pd"]
mask## pd
## Inf
all_bdry_profiles <- list()
linc <- c(rep(0.05,7),0.01)
rinc <- c(rep(0.05,7),0.01)
for (counter in 1:8)
{
all_bdry_profiles[[counter]] <- profile_likelihood(
profile_parameter=pnames[counter],
increment_left=linc[counter],
increment_right=rinc[counter],
num_steps_left=50,
num_steps_right=50,
alpha=0.95,
optim_param_vector=bdry_optim_results[[1]]$par,
env_dat=env_dat,
occ=occ,
mask=mask,
num_threads=6
)
}
names(all_bdry_profiles) <- pnamesNow plot these profiles:
par(mfrow=c(3,3))
plot_tool(all_bdry_profiles,1)
plot_tool(all_bdry_profiles,2)
plot_tool(all_bdry_profiles,3)
plot_tool(all_bdry_profiles,4)
plot_tool(all_bdry_profiles,5)
plot_tool(all_bdry_profiles,6)
plot_tool(all_bdry_profiles,7)
plot_tool(all_bdry_profiles,8)
These are sufficiently dome-shaped, suggesting the likelihood
function is sufficiently well-behaved in the vicinity of the maximum we
found, and inferences can be made. Note these profiles look essentially
the same as those obtained previously, except the \(\sigma\) profiles have been switched around
(which can happen, given redundancy in parameters explained in “How to
fit xsdm models with species occurrence data using xsdm”). The overall
lesson is, when optimizing the xsdm likelihood function gives a best
model with \(p_d\) close to \(1\) and a non-dome-shaped profile for \(p_d\), use the boundary model with \(p_d = 1\). We also saw a demonstration of
the xsdm functionality for fitting boundary models. Other
boundary models can also be fitted. See the document “Unusable models:
when a model does not have a maximum likelihood” for more examples of
fitting boundary models.
